Suzuki 25 HP Outboard Motor - Model DF25ATLW5

(1)
$4,45500 USD $4,55500

4-STROKE OUTBOARD OIL INCLUDED ✓

5 YEAR WARRANTY & REGISTRATION INCLUDED ✓

LIFT-GATE SERVICE INCLUDED ✓

MSRP: $6,110

Shaft

20" (Long)

Weight

158.0 lb

Starting

Electric

Steering

Remote

Trim & Tilt

Power Trim & Tilt

The DF25A EFI sets a new benchmark as the world's premier 25 HP outboard engine, boasting Lean Burn and Battery-Less Electronic Fuel Injection innovations. This "Next Generation" portable four-stroke outboard is not only impressively lightweight but also delivers smooth operation, instant ignition, outstanding acceleration, unmatched performance, and optimal fuel efficiency. Living up to our legacy of producing lightweight marine engines, the DF25A EFI stands out as the lightest in its 18.4kW (25PS) four-stroke category, showcasing our commitment to advanced technology.

Shipping

(3-9 Business Days) with Freight Shipping

In the Box
  • 6 gal Fuel Tank
  • Fuel Line
  • Owner's Manual
  • Aluminum Propeller
  • Tool Kit
  • Standard Side Mount Control Box and Harness
  • Suzuki's Newest 5-Year Manufacturer Warranty
  • Remote Control Cables NOT INCLUDED * Due to variating size requirements

Specifications
  • Model
    DF25 ATLW5
  • Weight
    158.0 lb
  • Manufacturer
    Suzuki
  • Country of Manufacture
    Thailand
  • Horsepower
    25 HP
  • Shaft Length
    20" (Long)
  • Steering
    Remote
  • Starting
    Electric
  • Trim & Tilt
    Power Trim & Tilt
  • Fuel Delivery
    EFI
  • Fuel Tank
    External
  • Cylinder(s)
    3
  • Displacement
    29.8 (489)
  • Bore and Stroke
    2.80 x 2.68 ()
  • RPM Range
    5000 - 6000 RPM
  • Ignition System
    Digital CDI
  • Induction Scavenging
    SOHC
  • Valves per Cylinder
    4
  • Fuel Type
    Unleaded Gasoline (87 octane)
  • Oil Type
    SAE 10W-30 or SAE 10W-40
  • Oil Capacity
    1.6 (1.5)L
  • Lubrication
    Wet Sump; Trochoid Type Cam-Driven Oil Pump
  • Alternator
    Manual 12V 14A / Electric 12V 14A
  • Cooling System
    Water-Cooled
  • Saltwater Rated
    Yes
  • Gear Ratio
    2.09:1
  • Gear Shift
    Forward-Neutral-Reverse (front-mounted lever)
  • Propeller
    3 x 10.25 x 11
  • Internal Battery
    No

Features
  • Battery-Less Electronic Fuel Injection
  • Easy Start - Recoil Starter
  • Lean Burn Control
  • Over-Rev. Limiter
  • Low Oil Pressure Caution
  • Digital CDI
  • Fresh Water Flushing System
  • Shallow Water Drive
  • Suzuki Anti-Corrosion System
  • Suzuki's Newest 5-Year Manufacturer Warranty

Shaft Length Guide

Learn More

Direct Intake And Engine Cover Ventilation

Direct Intake And Engine Cover Ventilation

A smoother, cooler airflow to the direct intake system is made possible by a revised engine cover design, which increases engine running efficiency. Together with a newly built air cleaner, the engine produces more power from a smaller displacement. The rotating flywheel lowers engine cover temperatures by venting warm air from the recoil cover, inner air intake, and engine top cover.

First In Class With Roller Rocker Arms

First In Class With Roller Rocker Arms

These are the first outboards in their categories to use a roller with internal bearings on the cam slipper surface for both the intake and exhaust valves. The roller converts the contact between the camshaft and rocker arm from a sliding to a rolling movement, which reduces friction during rocker arm operation.
